UT213A
New
UT213 series is 400A digital clamp meter with CAT III 600V safety standards. These meters are designed for electricians and HVAC/R technicians. The built-in flashlight also makes these meters useful tools when working in dark environments.
1. Auto range
2. 4000 display count, 3/s sampling rate
3. NCV, non-contact voltage
4. Frequency and duty ratio
5. 30mm large jaw,Continuity Buzzer
6. Data hold; LCD backlight
7. Auto power off,Relative Mode,Flashlight
10 Item Items
Hurry, Selling Fast!
Availability date:
By buying this product you can collect up to 6 loyalty points. Your cart will total 6 points that can be converted into a voucher of S$ 1.20.
UNI-T UT213A Digital Clamp Meter
UT213 series is 400A digital clamp meter with CAT III 600V safety standards. These meters are designed for electricians and HVAC/R technicians. The built-in flashlight also makes these meters useful tools when working in dark environments.
1. Auto range
2. 4000 display count, 3/s sampling rate
3. NCV, non-contact voltage
4. Frequency and duty ratio
5. 30mm large jaw,Continuity Buzzer
6. Data hold; LCD backlight
7. Auto power off,Relative Mode,Flashlight
Recipient :
* Required fields
or Cancel
Specifications | Range | UT213A |
AC current (A) | 400A | ±(1.8%+9) |
AC voltage (V) | 600V | ±(1.2%+5) |
DC voltage (V) | 600V | ±(0.8%+1) |
Resistance (Ω) | 40MΩ | ±(1%+2) |
Capacitance (F) | 100μF | ±(4%+5) |
Frequency | 10Hz~1MHz | ±(0.1%+4) |
Features | ||
Display count | 4000 | |
Auto range | √ | |
Jaw opening | 30mm | |
Diode | Around 1.5V | |
NCV | √ | |
Data hold | √ | |
Relative mode | √ | |
LCD backlight | √ | |
Flashlight | √ | |
Auto power off | √ | |
Continuity buzzer | √ | |
Low battery indication | √ | |
Input protection | √ | |
Input impedance for DCV | √ | |
General Characteristics | ||
Power | 1.5V battery (R03) x 3 | |
Display | 38mm x 24mm | |
Product net weight | Red and grey | |
Product color | 280g | |
Product size | 220mm x 75mm x 40mm |
